The EMAX 250 Series 7.5 HP 80 Gal. 2-stage 3 Cylinder, single phase air compressor is designed for up to 50,000-hours of use with proper maintenance. This EMAX air compressor is equipped with an all-cast iron splash lubricated pump producing 26CFM at 100 PSI. It also features industrial grade 1750 RPM electric motor, magnetic starter, manual drain valve, 80 Gal. powder coated ASME tank with 1/4 in. mounting pads, OSHA approved 13 G steel belt guard, 3/4 in. air outlet, all back by the best warranty around. EMAX air compressors are built and tested in Ohio with reliability and durability in mind. 1 Year Standard, 5 Year Extended, Lifetime Extended with maintenance kit
Specification | Description |
---|---|
Brand | EMAX |
Country of Origin | Made in USA |
Air Delivery SCFM At 90 PSI | 26 CFM 100 PSI |
Airflow Volume | 26 CFM |
Air Outlet Size | 0.75 in. |
Amperage | 32 Running Amps |
Compressor Horsepower | 7.5 HP |
Compressor Maximum PSI | 175 PSI |
Compressor Operation | Automatic start/stop |
Compressor Tank Capacity | 80 gal |
Compressor Type | Oil lubricated |
Compressor Voltage | 230V |
Connection Type | NPT |
Drain System | Manual tank drain |
Drive Type | Belt Drive |
Engine Brand | Industrial Electric Motor |
Features | SOLID cast iron Low RPM Pump, 1 Year Standard, 5 Year Extended, Lifetime Extended with maintenance kit, Silent air silencer compatible |
Maximum RPM | 640 Pump RPM |
Phase | Single |
Number Of Power Speeds | Single |
Power Type | Electric |
Primary Color | Yellow |
Primary Material | Steel |
Product Height | 70 in. |
Product Length | 31 in. |
Product Weight | 875 lb. |
Product Width | 24.5 in. |
Pump Life | 50,000 hr. |
Pump Material | Cast iron |
Pump Oil Capacity | 1.4 qt. |
Stage Type | Two-Stage |
Tank Fill Time | 4-5 min. |
Tank Orientation | Vertical |
Warranty | 1 Year Standard, 5 Year Extended, Lifetime Extended with maintenance kit |
Manufacturer Part Number | ESL07V080Y1 |
