This EMAX 10 HP 80 Gallon Industrial Air Compressor is a 2-stage pressure lubricated, SINGLE PHASE, V4 vertical piston SILENT AIR compressor designed for up to 60,000 hours of commercial or industrial use with proper maintenance. This EMAX air compressor delivers 38 CFM at 100 PSI, maximum PSI 175. The unit features industrial grade electric motors at 1750 maximum RPM, Pump 800 Maximum RPM and 40 running AMPS, magnetic starters, manual bal valve tank drain, and powder coated ASME tank 200PSI. This air compressor is paired with cast iron, 60,00 Hours rated, patented pressure lubricated reciprocating pump. Engineered and manufactured in the USA our patented Silent Air System dissipates compressor intake noise by channeling the intake air through a series of ba e plates. This low-pro le system adds 4 levels of air fltration along with making the compressor quiet, reducing DBA ratings by as much as 50%. Now that's being seen but not heard! Our Industrial Plus series come with standard features and only the best quality components. All backed by the best warranty in the industry. The EMAX includes our patented, MADE IN THE USA, SILENT AIR system, installed. ETL,UL,CSA, ASME Certified. Eligible for LIFETIME PUMP WARRANTY, 1 Year Standard, 5 Year Extended.

• MADE IN USA
• Patented Pressure Lubricated Pump
• Silent Air Technology helps this air compressor run quietly
• All steel connecting rods with replaceable rod bearing inserts can be rebuilt
• Easy Spin-on Re-usable oil filter
• Oil pressure gauge & level site glass
• Removable 100% cast iron cylinders are more stable under heavy workloads and do not warp from heat
• All cast iron cylinder heads are more durable and dependable
• Disc valve design intake and exhaust valves come right out of the top of the cylinder head where they can be serviced in minutes
• Top quality compression and oil rings ensure performance with low oil carry over (1-5 PPM)
• Precision ground pistons machined to tight tolerances ensures low oil carry over
• Premium non-absorbent gaskets prevent oil seepage from pump
• All cast iron flywheel with built-in fan gives the pump more throw on the compression stroke which will result in fewer loads on the electric motor
• Built-in head unloaders
• Inter-cooler allows air to be cooled between stages while the air cooled. After-cooler provides a second cooling stage that cools the air before it goes into the tank
• Large 1-3/8 in. output shaft
• Dynamically balanced armature for low vibration levels
• ETL, CSA, ASME, UL Certified
• Eligible for EXTENDED lifetime pump warranty
• 1 Year Standard, 5 Year EXTENDED warranty available
• Maximum Pump RPM: 800, for extended life
• Running Amperage: 40
• Manual Tank Drain
• 40 CFM @ 90 PSI & 42 CFM @ 40 PSI
• Industrial Motor: 1750 RPM
• Maximum PSI: 175
• ETL,UL,CSA, ASME Certified
• Running Amps: 40
• Single Phase 208/230 volt
• Air Outlet size: 3/4 in.
• Solid Cast Iron Crankcase with oil sight glass NOT Aluminum
• Steel Crankshaft with Tapered Roller Bearings for Solid Pump Support
• Powder coated 200 PSI ASME certified 80 gal. tank- approved in all 50 states
• Weight: 810 lb.
• Prewired Magnetic starter
• Pump Oil Capacity: 2.5 qt.
• Manual ball valve tank drain
• Dimensions: 38 x 42 x 72 in. (LxWxH)
