EMAX 7.5HP 1PH 45CFM@100PSI 230V 120 Gallon Tank with Air Dryer Rotary Screw Compressor-ERIK070001
Item # 234326799
Neighbor’s Club Members earn points with purchases.
EMAX 7.5HP 1PH 45CFM@100PSI 230V 120 Gallon Tank with Air Dryer Rotary Screw Compressor-ERIK070001
Item # 234326799
This item is available online only
Out of stock delivering to
37027
This item is not available
Search Stores
Temporarily unavailable
Neighbor’s Club Members earn points with purchases.
EMAX Compressors 7.5HP new generation Industrial Rotary Screw series have been built to exacting standards, to provide years of reliable service with a 60,000-pump life expectancy. Our Industrial series rotary line offers superior performance, a slick design and quite operation. The sound proof cabinet helps reduce operational noise to a minimum. Our Industrial Rotary Screw Air Compressors are built with premium standard features, offering the Logik 9 smart controller giving you the visual ability to set pressures, alarms and schedules. The controller has multi-unit control giving you the ability to run multiple Rotary's with a master/slave relationship. These units are equipped with V-belt drive, 1750RPM premium motor, MANN Filters for superior filtration, 8000HR oil and all back by the best warranty program! This unit is mounted to a horizontal, ASME certified 80 Gallon receiving tank with a patented swingarm mounted, refrigerated 30CFM 115Volt air dryer, for small foot print and easy maintenance. 1 Year Standard warranty, extended 5 Year warranty with Maintenance kit.1 Year Standard, 5 Year Extended with Maintenance kit
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on air compressors? Check out our air compressor FAQs in the product documents section.
- Pump life: 60,000 hours
- RotorComp rotary screw pump - Made in Germany
- Cabinet: Made in Italy
- 24.01 CFM @100 PSI, 20.48 CFM @145 PSI Maximum
- Starter Type: DOL
- Drive type: V Belt Drive
- Controller type: Logik 9
- Inlet Valve type: Poppet valve
- Compressor Outlet connection: 3/4 in. NPT
- Industrial electric Motor with Slow 1750 RPM
- Automatic start/stop operation
- Patented SWING arm dryer mount
- 30 CFM 115 Volt Air dryer, weight: 110 lb., 134A environmentally friendly refrigerant, Dew point: 37-50, Dryer pipe size: 1/2", Max rated inlet temp: 140, Max Ambient Temp: 122, Built-in coalescing filter
- 80 Gallon Horizontal ASME certified tank in all 50 states, Max Tank PSI: 200PSI
- Drain type: Ball Valve
- Dimensions: 98 x 48 x 128in. (LxWxH)
- 7.5 Horsepower, 320 Volt, 24 CFM @ 100 PSI, 20.48 CFM @ 145 PSI
- Weight: 1200 lb.
