WorkHorse Sprayers 60 gal. 7 Nozzle 12V Trailer Tow-Behind Sprayer
$1,099.99
Sale
Was$949.99
Save $95.00
WorkHorse Sprayers 60 gal. 7 Nozzle 12V Trailer Tow-Behind Sprayer
Limited Time Deal
WorkHorse Sprayers 60 gal. 7 Nozzle 12V Trailer Tow-Behind Sprayer
Item # 163710799
$1,099.99
Sale
Was$949.99
Save $95.00
or
or
Neighbor’s Club Members earn points with purchases.
Limited Time Deal
WorkHorse Sprayers 60 gal. 7 Nozzle 12V Trailer Tow-Behind Sprayer
Item # 163710799
$1,099.99
Sale
Was$949.99
Save $95.00
or
or
$36/mo.† suggested payments with 24 Months Financing or earn $42 in Rewards+ on this purchase.
Valid 5/15/2026 - 7/5/2026
Valid 5/15/2026 - 7/5/2026
This item is available online only
Delivery to
For delivery, this item requires a Big & Bulky handling fee.
Neighbor’s Club Members earn points with purchases.
This WorkHorse Sprayers 60 gal. 7-Nozzle 12V Trailer Tow-Behind Sprayer is perfect for pastures, row crops and other large areas. Effective in covering larger premises in off-road terrains, this tow-behind sprayer is recommended for commercial use. The trailer sprayer has a durable polyethylene tank that reduces the scope of frequent replacements and repairs.
Looking for more information on sprayers? Check out our guide on agricultural and lawn sprayers in the product documents section.
- 7-nozzle boom sprayer with a 60 gal. tank
- Provides 140 in. of spray coverage for powerful use
- Backed by a 1-year limited warranty for assurance
- Trailer sprayer is made in the USA
- Perfect for pastures, row crops and other large areas
- 5.3 GPM, 12V pump for convenience
- Delivers 0 to 60 PSI of pressure for durability
- Handgun has a pistol grip, 25 ft. EPDM hose
- Maximum horizontal spray of 25 ft. and maximum vertical spray 12 ft.
- Durable polyethylene trailer sprayer tank for long-lasting use
- 3/8 in. PVC reinforced spray hose for added strength
- Heavy-duty manifold design and heavy-duty frame construction for lasting strength
- Equipped with an 8 ft. universal wiring harness
- Chemical-resistant and RoundUp-ready for easy use
| Brand | WorkHorse Sprayers |
|---|---|
| Country of Origin | Made in USA |
| Boom Maximum Spray Width | 11.5 ft |
| Boom Nozzle Count | 7 |
| Boom Style | Folding Boom |
| Chemical Compatibility | Fertilizer |
| Features | Handgun Included |
| Hose Diameter | 3/8 in. |
| Hose Length | 25 ft. |
| Maximum Flow Rate | 5.3 GPM |
| Maximum Operating Pressure | 60 PSI |
| Power Type | 12 Volt |
| Product Height | 33.5 in. |
| Product Length | 40 in. |
| Product Weight | 125 lb. |
| Product Width | 32.5 in. |
| Pump Type | Diaphragm |
| Boom Width | 10 ft |
| Spray Method | Boom Spraying (Precision), Spot Spraying |
| Tank Material | Polyethylene |
| Warranty | 1 Year |
| Manufacturer Part Number | G23-LG657DTS |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 32 Questions
Newest questions
Q: How can you attach this to a standard 2" UTV hitch
7 days ago2 Answers
- A: Thank you for reaching out! To attach the trailer tongue to a standard 2" UTV hitch receiver, you will need a hitch pin (not included with the sprayer). Since the sprayer is designed to be universal, it requires this standard pin to secure the tongue's clevis-style hitch to your UTV’s drawbar. You can find a compatible hitch pin at most hardware stores, farm supply centers, or the same location where you purchased the sprayer.6 days agoHelpful?
Q: does this have breakaway sprayer arms
a year ago1 Answer
- A: The boom does have breakaway arms to allow the outer boom to fold backwards if you should hit something, as well as allow the boom to fold up for storage.a year agoHelpful?
Q: Can I replace the spray tips with tips that have a different spray pattern ? Will standard tips fit this sprayer ?
a year ago1 Answer
- A: When choosing tips, you need to watch the GPM the tips are rated for and not exceed what the pump will put out at certain pressures. Also, need to keep in mind that the orientation of certain tips may different than others. Also, some tips may require a different type cap. The tips can be changed out, but you need to keep the aforementioned things in mind when choosing tips.a year agoHelpful?
Q: Can I purchase "Flat Free" tires / wheels that will fit this sprayer ?
a year ago1 Answer
- A: Hi, We do not stock them, however, you may be able to purchase directly from Work Horse using their contact information below. ***WORKHORSE*** https://workhorsesprayers.com/support/ or call Phone: 1 (800) 654-9808 Hours: Mon-Fri 8am – 4:30pm (EST)a year agoHelpful?
Q: Can i get it pr assembled
a year ago1 Answer
- A: John, the sprayer is mostly assembled, other than the boom and a few small parts that go on the sprayer. This does not come preassembled. You could talk to your local Tractor Supply and see if they would assemble it for you, but I'm sure there probably would be a charge, not sure, as I don't work for TSC. I just know I've talked to customers that have said their local Tractor Supply had assembled their sprayers.a year agoHelpful?
Q: Does it have a chemical agitator?
2 years ago1 Answer
- A: Kate, thank you for your interest in the Workhorse 60-gallon trailer sprayer from Tractor Supply. This sprayer does have a manifold on it with a bypass line, that you can crack open to allow circulation back into the tank to help a little with agitation. Doing so, also decreases your pressure, if opened too much.2 years agoHelpful?
Q: what brand of pump is on the sprayer & what size are the tires
2 years ago1 Answer
- A: Hi, Here is the information we received from the vendor- "The pump on this unit is: 5.3GPM 3/4" Quick Attach Wheels: 15” 6.00/6."2 years agoHelpful?
Q: can you add a tongue hitch coupler to the sprayer?
2 years ago1 Answer
- A: Hi there, For this specific inquiry please contact the manufacturer. WorkHorse Sprayers https://workhorsesprayers.com/support/ Phone: 1 (800) 654-9808 Email: sales@green-leaf.us2 years agoHelpful?
Q: Can pull this behind 24 hp lawn tractor
2 years ago1 Answer
- A: Hi Rocky. Yes, you can. This pump requires the following Power Type-12V battery, so make sure this is something your lawn tractor has.2 years agoHelpful?
Q: Can you shut one side of the sprayer down? Or shut a couple of nozzles off?
2 years ago1 Answer
- A: Hi, Yes you can close off some of the nozzles.2 years agoHelpful?
1 - 10 of 32 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 32 Questions
Newest questions
Q: How can you attach this to a standard 2" UTV hitch
7 days ago2 Answers
- A: Thank you for reaching out! To attach the trailer tongue to a standard 2" UTV hitch receiver, you will need a hitch pin (not included with the sprayer). Since the sprayer is designed to be universal, it requires this standard pin to secure the tongue's clevis-style hitch to your UTV’s drawbar. You can find a compatible hitch pin at most hardware stores, farm supply centers, or the same location where you purchased the sprayer.6 days agoHelpful?
Q: does this have breakaway sprayer arms
a year ago1 Answer
- A: The boom does have breakaway arms to allow the outer boom to fold backwards if you should hit something, as well as allow the boom to fold up for storage.a year agoHelpful?
Q: Can I replace the spray tips with tips that have a different spray pattern ? Will standard tips fit this sprayer ?
a year ago1 Answer
- A: When choosing tips, you need to watch the GPM the tips are rated for and not exceed what the pump will put out at certain pressures. Also, need to keep in mind that the orientation of certain tips may different than others. Also, some tips may require a different type cap. The tips can be changed out, but you need to keep the aforementioned things in mind when choosing tips.a year agoHelpful?
Q: Can I purchase "Flat Free" tires / wheels that will fit this sprayer ?
a year ago1 Answer
- A: Hi, We do not stock them, however, you may be able to purchase directly from Work Horse using their contact information below. ***WORKHORSE*** https://workhorsesprayers.com/support/ or call Phone: 1 (800) 654-9808 Hours: Mon-Fri 8am – 4:30pm (EST)a year agoHelpful?
Q: Can i get it pr assembled
a year ago1 Answer
- A: John, the sprayer is mostly assembled, other than the boom and a few small parts that go on the sprayer. This does not come preassembled. You could talk to your local Tractor Supply and see if they would assemble it for you, but I'm sure there probably would be a charge, not sure, as I don't work for TSC. I just know I've talked to customers that have said their local Tractor Supply had assembled their sprayers.a year agoHelpful?
Q: Does it have a chemical agitator?
2 years ago1 Answer
- A: Kate, thank you for your interest in the Workhorse 60-gallon trailer sprayer from Tractor Supply. This sprayer does have a manifold on it with a bypass line, that you can crack open to allow circulation back into the tank to help a little with agitation. Doing so, also decreases your pressure, if opened too much.2 years agoHelpful?
Q: what brand of pump is on the sprayer & what size are the tires
2 years ago1 Answer
- A: Hi, Here is the information we received from the vendor- "The pump on this unit is: 5.3GPM 3/4" Quick Attach Wheels: 15” 6.00/6."2 years agoHelpful?
Q: can you add a tongue hitch coupler to the sprayer?
2 years ago1 Answer
- A: Hi there, For this specific inquiry please contact the manufacturer. WorkHorse Sprayers https://workhorsesprayers.com/support/ Phone: 1 (800) 654-9808 Email: sales@green-leaf.us2 years agoHelpful?
Q: Can pull this behind 24 hp lawn tractor
2 years ago1 Answer
- A: Hi Rocky. Yes, you can. This pump requires the following Power Type-12V battery, so make sure this is something your lawn tractor has.2 years agoHelpful?
Q: Can you shut one side of the sprayer down? Or shut a couple of nozzles off?
2 years ago1 Answer
- A: Hi, Yes you can close off some of the nozzles.2 years agoHelpful?
1 - 10 of 32 Questions
Similar Items
-
-
-
-
-
-
-
-
Top Rated
-
-
-
-
Items You May Like
-
-
Top Rated
-
-
-
-
-
-
Top Rated
-
-
-
-
Customers Also Bought
-
Top Rated
-
-
Subscription Eligible
-
-
-
Top Rated
-
Top Rated
-
-
-
Top Rated
-
-
Reviews
Summary of Reviews
The 60-gallon tow-behind sprayer has a large coverage area and sturdy construction, but some customers reported issues with the pump, pressure switch, and assembly instructions. The product has mixed ...
- English
- German
- French
- Spanish
- Portuguese
- Italian
- Korean
- Chinese
- Japanese
- Arabic
Most Helpful Favorable Review
5 out of 5 stars.
Best Sprayer!
5 years ago
This size of sprayer is the way to go! It works well and has good retracting arms on the sprayers, spring loaded. The 7 foot span allows you to spray well. AMERICAN MADE!!!
15 people found this helpful
Show Reviews:
Most Helpful Critical Review
1 out of 5 stars.
Bah!
5 years ago
Loosing pressure and all but two sprayer head are dribbling after one use.
5 people found this helpful
Show Reviews:
- purchase
- satisfaction
- setup
- instructions
- price
- quality
- size
- spraying
1 to 4 of 33 Reviews .
1 – 4 of 33 Reviews
Most Recent
Review 1
4 out of 5 stars.
Challenging Assembly Sprayer
6 months ago
I haven’t used this sprayer yet. The illustrations were, at best, poor and without written instructions.
I finally managed to assemble it but getting the hose clamps on to the boom was another challenge.
I have another Workhorse sprayer that is just a tank and spray hose that has worked very well, so I’m hoping that this one will prove to be worth the expense.
Response from Fimco Industries:
6 months ago
Fimco Industries
Thank you for your purchase of the Workhorse 60-gallon trailer sprayer from Tractor Supply. We have been diligently updating those manuals this year, as we acquired the Workhorse sprayer line last year and have heard that those original manuals have not been the greatest. The manual for this sprayer was just recently approved by our engineering team and if you would like an updated manual that not only gives better instructions for assembly, but also better parts break downs and more information, please contact our customer service team at 888-433-6631 and they'll be happy to send you one.
Review 1
5 out of 5 stars.
Good purchase
11 months ago
Love it sprayer. Works great Can take fewer trips through the field with the 7 nozzles
Yes, I recommend this product.
Response from Fimco Industries:
11 months ago
Fimco Industries
Karen, thank you for your purchase of the Workhorse 60-gallon trailer sprayer from Tractor Supply. Glad that you love your new sprayer and that it's working great for your spraying needs.
Reviews 3
3 out of 5 stars.
Looks great, Poor delivery, late delivery.
a year ago
Product looks good, arrived on a pallet and dropped off at my mail box not at the house as paid for. It has rained every other day here and you need a dry place to assemble this product. This product arrived 7 days after it was scheduled to be delivered. Driver said TCS always does this!
SweepstakesYes
Yes, I recommend this product.
Response from Fimco Industries:
a year ago
Fimco Industries
Thank you for your purchase of the Workhorse 60-gallon trailer sprayer. Not sure why it took so long to receive the item. We fulfilled the order and every one of those units that we've sold in the last two months have shipped out within two business days of us receiving the order, some even shipped the same day. All depends on when we received the order to start. As for delivery, once an item ships, it's out of our hands. We do hope that once the rain stops and you get the sprayer assembled that you'll like it and it handles your spraying needs.
Bardstown, Ky
Review 1
3 out of 5 stars.
Better put your thinking cap on for assembly
a year ago
First, I am very handy and mechanically inclined but the directions for this are horrible. Got it all together and only 3 of 7 sprayers worked. Reached out to the company but never got a response. Trouble shot it myself. 4 of the sprayers would not work with the filters installed. That being said I sprayed 60 gallons of herbicide on my acreage (with filters removed and all 7 sprayers working) and it was very nice with this sprayer. Could even spray the fence row with the wand. I am hoping this will be a worthwhile purchase.
Yes, I recommend this product.
Response from Fimco Industries:
a year ago
Fimco Industries
Thank you for your purchase of the Workhorse 60-gallon 3PT sprayer from Tractor Supply. Sorry that the check valve strainers on four of the nozzles weren't working. Could be the ball in there may be sticking to the spring. Try tapping them on a hard surface to try and help loosen them a little, but also please call our customer service team at 888-831-0027 and they'll be happy to assist you and get you out replacements. Not sure how you reached out, as our team is exceptional with taking care of the customers. Fimco acquired the Workhorse sprayer line last year and we have heard from several customers about hose original manuals. We are currently updating those manuals to be more uniform with our own sprayer manuals, reflecting more information and assembly instructions. We have about 2/3rds of them done awaiting final approval from our engineering team. Unfortunately, this isn't one of the ones currently awaiting approval, we're waiting on the files from the engineering team to start the manual. Overall, we hope you'll be happy with your new sprayer.
